Public lighting LED, Light Emitting Diode To see the technical characteristics of each produst press their name. For more information click here |
| Colour temperature | Cold white 5,500K ~ 6,300K |
| Neutral white 5,000K ~ 5,500K | |
| Warm white 2,800K ~ 3.200K | |
| Operating temperature | - 30º ~ 60º C. (55ºC to a 25ºC environment) |
| Enviornamental humidity | 80% +/- 5 (outdoor humidity 100%) |
| Consumption | 110V/0.61A ~ 220V/0.31A |
| Weight | About 4.5Kg |
| Lamp size | 620mm x 203mm x 115mm Caliber 50mm |
| Efficience | Cold white 60 ~ 65lm/w |
| Neutral white 55 ~ 50lm/w | |
| Warm white 45 ~ 40lm/w | |
| Lamp post | 4m - 6m |
| Opening | 16m |
| Certificates | CE, ROHS, IP65, UL, 3C, CB, CNS, ISO9001 |
| Life span | Over 50.000 hrs |
| Colour temperature | Cold white 5,500K ~ 6,300K |
| Neutral white 5,000K ~ 5,600K | |
| Warm white 2,800K ~ 3.200K | |
| Operating temperature | - 35º ~ 50º C. (55ºC to a 25ºC environment) |
| Enviornamental humidity | 80% +/- 5 (outdoor humidity 100%) |
| Consumption | 110V/1.12A ~ 220V/0.59A |
| Weight | About 9.5Kg |
| Lamp size | 790mm x 325mm x 190mm Caliber 50mm |
| Efficience | Cold white 60 ~ 65lm/w |
| Neutral white 55 ~ 50lm/w | |
| Warm white 45 ~ 40lm/w | |
| Lamp post | 8m - 9m |
| Opening | 28m ~ 30m |
| Certificates | CE, ROHS, IP65, UL, 3C, CB, CNS, ISO9001 |
| Life span | Over 50.000 hrs |
| Colour temperature | Cold white 5,500K ~ 6,300K |
| Neutral white 5,000K ~ 5,500K | |
| Warm white 2,800K ~ 3.200K | |
| Operating temperature | - 30º ~ 60º C. (55ºC to a 25ºC environment) |
| Enviormental humidity | 80% +/- 5 (outdoor humidity 100%) |
| Consumption | 110V/1.61A ~ 220V/0.8A |
| Weight | About 12.5Kg |
| Lamp size | 800mm x 383mm x 205mm Caliber 50mm |
| Efficience | Cold white 60 ~ 65lm/w |
| Neutral white 55 ~ 50lm/w | |
| Warm white 45 ~ 40lm/w | |
| Lamp post | 10m - 12m |
| Opening | 30m ~ 34m |
| Certificates | CE, ROHS, IP65, UL, 3C, CB, CNS, ISO9001 |
| Life span | Over 50.000 hrs |
| Colour temperature | Cold white 5,500K ~ 6,300K |
| Neutral white 5,000K ~ 5,500K | |
| Warm white 2,800K ~ 3.200K | |
| Operating temperature | - 35º ~ 50º C. (55ºC to a 25ºC environment) |
| Enviormental | 80% +/- 5 (outdoor humidity 100%) |
| Consumption | 110V/2A ~ 220V/1A |
| Weight | Cerca 12.5Kg |
| Lamp size | 790mm x 325mm x 190mm Caliber 50mm |
| Efficience | Cold white 60 ~ 65lm/w |
| Neutral white 55 ~ 50lm/w | |
| Warm white 45 ~ 40lm/w | |
| Lamp post | 12m - 14m |
| Opening | 36m ~ 44m |
| Certificates | CE, ROHS, IP65, UL, 3C, CB, CNS, ISO9001 |
| Life span | Over 50.000 hrs |
